LW45B basic type sliding table saw panel saw with good price

Basic type 45 degree sliding table saw

two saw blades 300/120mm

sliding table length 2800mm(optional),

max cutting length 2600mm

4+0.75 kw motor

manual lifting and angel adjustment

Inquire now

Inquiry

name:*

phone:

email:*

country:

message:*

Product Details

Sliding Table Saw Wood Cutting Machine

1.Aluminum profile sliding table

2.The worktable is made of high-strength steel plate, which is not easily bent or deformed.

3.Apply to processing all kinds of wood boards,Particle board, MDF, ABS Panels,

PVC Panels , Organic glass plates and solid wood and others with wood structure and similar hardness.

4.the guide rail of sliding table is round steel bar guide rail.

Configuration

Model	LW-45B
Net weight(kg)	550kg
Out size(mm)	280028001200mm
Sliding table size	2800*375mm
Maximum cutting plate length	2600mm
Maximum cutting board thickness	75mm
Saw blade angle	45-90 degree
main Saw blade diameter	300mm
grooving saw blade diameter	120mm
Main saw blade speed	4500/6000rpm
grooving saw blade speed	6000/8000rpm
install axle diameter	30mm
install axle2 diameter	20mm
Voltage	380v 50Hz 3Phase, 220v 1phs 50hz
main saw blade lifting	Manual lifting
angle display	Circular scale
sliding table model	normal
Auxiliary worktable	Two pieces
Aluminum sliding table	√
Chrome-plated round rod guide	√
Pure copper motor	√
Main saw power	4KW
Scribing saw power	0.75KW
